Airports

Bend Airport Noise and Air Quality Analysis, Bend, OR

Performed airport noise and air quality modeling and analysis for the Bend Airport project using methods provided by the FAA. The proposed action consisted of three phases and included expansion of the Epic Aircraft facility, a new eastside taxiway, future industrial development, and new associated internal access roads. Modeled three different years using INM version 7.0a. Modeling was performed for several types of aircraft including several types of propeller aircraft, business jets and helicopters. Identified several residential and commercial impacts and recommended noise mitigation measures. Plotted aircraft noise level contours and authored a detailed noise report. Provided contours in AutoCAD for client use. MM&A also performed air quality analysis using the FAA Emissions and Dispersion Modeling System (EDMS) version 4.2. Air quality issues related to traffic to and from the airport were analyzed using Oregon DEQ methods. Authored air quality technical report.

Grove Field Airport, Camas, WA

Performed a technical noise analysis for the Grove Field Airport Project. The Grove Field Airport project would expand the overall footprint of the facility and modify and extend the runway length to increase safety at the Airport. The purpose of the proposed action was to bring the Airport into compliance with FAA design standards for the Airport's existing Airport Reference Code (ARC) of A-I (small), while complying with Federal and State environmental regulations. Modeled airport noise using FAA INM 7.0a for 2009 and 2015. Identified potential noise impacts at several residential land uses near the airport and made recommendations for noise mitigation measures. Several residents have homes with direct runaway access and live in the area for airport access. Plotted aircraft noise level contours and authored a detailed noise report. Provided contours in AutoCAD for client use.

Deer Park Airport, Deer Park, WA

Performed an airport noise master plan study in accordance with FAA regulations using the FAA INM version 7.0b. Version 7.0b is the most current version of the FAA INM program. The Deer Park Airport proposes to expand the overall footprint of the facility to allow for future expansion. The proposed Master Plan includes additional hangers, storage, and maintenance facilities. In addition, the future plans also call for fuel storage and an aviation-compatible business park. Modeled noise contours for existing conditions and year 2019. Authored noise technical report and provided CAD files of the contours to the client for future use.

Phillips Petroleum Alpine Air Field, North Slope, Alaska

Constructed INM noise model using base maps provided by Phillips Petroleum and ABR, Inc. for 5000 foot airport in the north slope of Alaska. Performed on-site noise monitoring and noise model calibration over a 1-week period to include 20 monitoring locations surrounding the airport and performed flight track monitoring to include as input into the FAA IMN. The noise monitoring was performed in 1-second time intervals, and the data downloaded into a computer for post analysis. The data post analysis provided second-by-second time records for each aircraft event, and included Lmax, Leq, and SEL. The data was tabulated by aircraft type for use in the final report. The technical report included methods of analysis, noise modeling and monitoring results, and other general information, such as helicopter flight and noise level information. Budget: $40,000

Logan-Cache Airport, Logan, Utah

Performed an airport noise master plan study in accordance with FAA regulations using the FAA INM version 7.0 for the Logan-Cache Airport. The Logan-Cache Airport proposes to expand the overall footprint of the facility to allow for future expansion. The proposed Master Plan includes additional corporate hangers, terminals, storage, manufacturing and maintenance facilities. Additional space and plans for future fuel storage, an aviation-compatible business park and an air traffic control tower are also included. Under the current Master Plan there are no changes to the existing runway configurations. Modeled noise contours for existing conditions, year 2013 and year 2028. Modeling was performed for several types of aircraft including several types of propeller aircraft, business jets and commercial jets. Authored noise technical report and provided CAD files of the contours to the client for future use.

Prosser Airport INM Analysis, Prosser, WA

Performed a technical noise analysis for the Prosser Community Airport Runway Relocation Project. The purpose of this study was to evaluate the potential for aircraft noise impacts due to the relocation of the existing runways 1058 feet west of the current location. As part of the relocation additional properties would be acquired to extend the airport protection zone. Modeled airport operations using the FAA Integrated Noise Model and plotted aircraft noise level contours and authored a detailed noise report. Modeling was performed for the years 2005 and 2010 with and without the runway relocation. No FAA impacts were identified and no mitigation was recommended.

Portland International Airport, Portland OR

Performed a noise monitoring training seminar for the noise abatement group at Portland International Airport. Compiled a noise monitoring handbook for airport staff, gave a PowerPoint presentation on noise monitoring and reviewed equipment maintenance and calibration procedures. Performed reverse thrust noise measurements and assisted in a technical analysis of the effects of reverse thrust noise in nearby neighborhoods. Analyzed data and organized noise monitoring sessions.

Portland International Airport, Portland, Oregon

Assisted with the design of complete noise monitoring and flight tracking system. Recommended products and assisted in system specifications.

Seattle-Tacoma International Airport, Seattle, Washington

Assisted with the design of complete noise monitoring and flight tracking system. Recommended products and assisted in system specifications.

Seattle-Tacoma International Airport, Seattle, Washington

Designed a system for the measurement of noise transmission for homes located near the flight paths of aircraft at Seattle-Tacoma Airport. System included hardware and custom-written software with measurement and analysis of noise due to aircraft overflights.

Medford-Jackson County Airport, Medford Oregon

Performed detailed noise modeling and analysis using the FAA INM for the Medford-Jackson County Airport Runway Extension Project. Ploted aircraft noise level contours and authored a detailed noise report.

Traffic

Columbia River Crossing Project

David Evans and Associates, Inc./Oregon and Washington State DOTs, Portland, Oregon and Vancouver, Washington

The Columbia River Crossing project is a comprehensive, long-term transportation solution that addresses congestion, safety, and mobility problems on I-5 between Portland, OR and Vancouver, WA. Essential elements of the five-mile project include: replacement of the I-5 bridge, a light rail extension to Vancouver, rebuilding five closely-spaced interchanges, wider pedestrian and bicycle paths, and electronic tolling. Over the five years we have been involved, MM&A has performed traffic, bus and light rail noise analyses. We recommended sound walls in both states; requiring two different reasonability and feasibility analyses. We worked with the project environmental team and met with local residents, the U.S. Forest Service, and bicycle and pedestrian advocates on noise impacts related to the project.

SR 520 Bridge Replacement and HOV Project

Parametrix, Inc./Washington State DOT, Seattle, Washington

The purpose of the SR-520 Bridge Replacement and HOV project is to improve mobility for people and goods on SR 520 while minimizing negative impacts to neighborhoods and the environment. The SR-520 Project is one of the largest transportation projects in the State of Washington and MM&A has been working on the SR 520 project since September 2000, when it was called the Trans-Lake Washington Project. Since that time, we have authored five noise studies and are in the process of completing the last three. MM&A used the FHWA Traffic Noise Model (TNM) Version 2.5 to build several traffic models to assist with early design concepts in addition to working closely with community groups and attending several meetings with the client and city mayors on sound wall locations and design issues.

Pontoon Construction Project

Parametrix, Inc./Washington State DOT, Seattle, Washington

Michael was the Task Manager for noise and vibration analysis of the proposed Pontoon Construction Site Environmental Impact Statement. Analysis requirements include predicting potential noise and vibration impacts due to the construction and operation of two pontoon construction sites for the SR 520 Floating Bridge. Michael analyzed potential noise related to the construction of the facilities, haul truck traffic and heavy rail accessing the facilities. He also analyzed the general operations of the facility, including noise from concrete batch plants, haul trucks and other related noise sources. Mitigation measures were proposed for the site alternatives, including noise berms, sound wall and operational measures that would keep noise levels to within the Noise Control Ordinance in the Washington State Administrative Code. MM&A authored reports, met with the client and contractors and assisted with the final environmental documents.

137th Round-a-bout Project

DEA, Inc. /WSDOT/ City of Vancouver, Washington

MM&A performed technical noise and air quality analysis for a proposed round-a-bout in Vancouver, Washington. We modeled traffic noise using FHWA Traffic Noise Model, authored noise technical report, attended public meetings and performed construction noise analysis. MM&A authored both noise and air quality reports for the project.

West Main Street Realignment Project

OTAK, Inc. /WSDOT/City of Kelso, Washington

Noise Analysis: The West Main Street Realignment Project stems from concerns over growing traffic, congestion and accidents along the West Main Street corridor in Kelso, Washington. The goal of the project is to redevelop the streets in the area to deal with those issues, and at the same time provide a desirable business friendly environment. MM&A performed a detailed traffic noise study for this project which included monitoring noise levels within the project corridor, performing existing and future traffic noise projections using TNM, and conducting a detailed noise mitigation analysis. Noise mitigation was considered for all affected residences and two noise barriers along the southern portion of the new alignment were found to meet the WSDOT reasonable and feasible criteria.

Air Quality Analysis: The City of Kelso is located in an area that is in attainment of State and Federal air quality standards. Our analysis showed that no significant air quality impacts are expected from the traffic using the re-configured roadways. We also confirmed that the project meets the Conformity requirements of the Clean Air Act. MM&A authored the air quality technical report and worked with the client on specific air quality issues.

Intestate 205 Preservation and Auxiliary Lane Project

OBEC Inc. and Oregon DOT, Portland Oregon

Noise analysis Task Manager for construction and operation of two auxiliary lanes along I-205 from Stafford Road to I-5. Analysis requirements included measuring and predicting the existing noise environment along project corridor. Our team predicted noise impacts along the revised highway, worked with the project design team and performed a detailed analysis of potential noise walls options. For this project several wall options were analyzed, including a two wall system designed to accommodate the split level highway near Tualatin. Due to elevations issues, no walls met the ODOT feasibility and reasonability criteria. Interfaced directly with the client (ODOT), attended public and city meetings, authored the project noise technical report and obtained a nighttime construction noise variance.

Highway 217 Traffic Noise Study, Beaverton, Oregon

City of Beaverton and Oregon DOT, Beaverton Oregon

Performed a detailed traffic noise study for the addition of an auxiliary lane to Highway 217. Met with affected residents, monitored noise levels, performed existing and future traffic noise projections using TNM, and performed a detailed noise mitigation analysis. Analyzed noise walls in accordance with ODOT standards and attended public meetings to support the project with Dave Goodwin, ODOT. The noise walls for this area were not able to meet ODOT feasibility and reasonability criteria.

Sunnyside Road Widening and Improvements Project, Clackamas County, Oregon

Clackamas County and Oregon DOT

Performed initial EA's and final design noise analysis for the widening of Sunnyside Road between Interstate 205 and SE 172nd Avenue. Performed final design noise modeling analysis and provided base-of-wall (BOW) and top-of-wall (TOW) elevations for 11 individual noise barriers. Attended and made presentations at community meetings and with members of Clackamas County. Resolved issues with un-mitigated section of the roadway, and made on-site visit to concerned residents. Provided EA noise technical study and the final design noise technical report.

US 26: NW 185th Ave - Cornell Rd., Oregon DOT, Washington County, Oregon

Michael Minor & Associates has worked with ODOT on projects along the Sunset Highway for over 15 years. We worked extensively with several different ODOT construction managers on the Sylvan Interchange improvements, general highway widening projects, noise monitoring of nighttime constriction activities and blasting. We also assisted in obtaining noise variances from the City of Portland and Washington County. (2007)

I-205 Preservation and Auxiliary Lane, OBEC/Oregon DOT, Portland, Oregon

SR522: Cathcart Road Vicinity to US 2

WSDOT and Parametrix, Seattle, Washington

MM&A performed a detailed traffic noise analysis for improvements and widening of a 4.3-mile corridor of State Route (SR) 522 between the vicinity of Cathcart Road and United States Highway 2 (US 2) in the City of Monroe, Washington. MM&A performed measurements of the existing conditions, predicted the future No-Build and future Build noise levels and identified noise impacts. MM&A worked closely with WSDOT and the design team at Parametrix, Inc. to develop and include the noise reducing effects of 42-inch traffic safety barriers along the highway, which was elevated on an earth-berm, approximately 12 to 20 feet above the grade of the residences. The addition of the safety barrier was sufficient to reduce noise levels to well below the FHWA and WSDOT traffic abatement criteria, saving the State a substantial amount of cost by not needing any noise walls. MM&A also provided the project team with a detailed construction noise analysis, and a blasting noise analysis. The blasting was required at specific sites along the corridor and MM&A predicted blast levels and provided the State with blasting noise and vibration analysis and noise and vibration mitigation measures.

Downtown Bremerton Pedestrian/BTC Access Improvements

Exeltech Inc./WSDOT/City of Bremerton, Washington

MM&A performed technical noise and air quality analysis for several alternatives to improve the transportation access in Downtown Bremerton, Washington. Analysis requirements included measuring and predicting the existing noise environment along project corridor, which included surface and tunnel alignments. We also performed a construction noise analysis and reviewed proposed developments in the immediate area. The project was performed in conjunction with the Washington State Department of Transportation (WSDOT), the Federal Highway Administration (FHWA), Puget Sound Naval Shipyard (PSNS), Kitsap Transit, and the Federal Transit Administration (FTA).

Fern Valley Interchange Project, Phoenix, OR

Oregon Department of Transportation

This new interchange planned for I-5 near Medford has a unique diamond type intersection crossing. The crossing is shown to the right. The traffic drives on the wrong side of the road, making it easier for traffic to access the I-5 ramps and maintaining a smother traffic flow. In addition this project also had several residential areas near the project corridor, requiring the inclusion of I-5 in the traffic noise model. There is also a substantial level of heavy truck traffic in this area, further increasing noise levels. Finally, the community was very active on this project and reviewed all aspects of the proposed interchange. The final report recommended noise walls for a large manufactured home park located along the I-5 corridor, just south of the interchange.

Transit

North Link Light Rail EIS and Final Design

Parametrix, Inc. and Jacobs Engineering /Sound Transit, Seattle, Washington

Michael was the Noise Analyst for the updated North Link Extension, from the University of Washington to the Northgate Park and Ride. MM&A measured and analyzed existing noise conditions and predicted potential noise and vibration impacts as part of the environmental study. Michael authored the noise technical report and worked closely with Parametrix and Sound Transit on completion of the environmental analysis. Directly following the FEIS, Michael worked closely with Jacobs Engineering and Sound Transit to perform the final design of noise mitigation for the trackway from the tunnel portal to the Northgate Station. His analysis included allowing access of high rail vehicles through a noise wall, integrating a noise wall with a large retained wall in the retained cut section. Michael also provided Sound Transit with mitigation options that included a 23 foot sound wall, sound insulation and worked with the design team to design a detailed noise mitigation plan for this section of the corridor

Seattle Light Rail Initial Segment On-Call Noise and Vibration Consultant

Sound Transit, Seattle, Washington

MM&A, along with ATS Consulting were recently awarded an on-call noise and vibration contract directly with Sound Transit. Michael is performing post-construction noise and vibration testing of the initial segment from downtown Seattle to the Sea-Tac Airport. Testing includes performing noise and vibration measurements, verifying noise impacts and mitigation, and performing a supplemental noise and vibration analysis. Michael performed direct testing of trains to assure they meet contract specifications while working with Sound Transit to reduce noise levels of train mounted and intersection warning systems. Michael identified a section of track with vibration issues that were due to improper track grinding and is working with Sound Transit to solve potential issues with rail corrugation and increased noise levels.

Sea-Tac Airport to S 200th Park and Ride Light Rail Final Design

Jacobs, Inc. /Sound Transit, Seattle, Washington

Michael was the lead noise analyst for the final design noise and vibration mitigation for the Link Light Rail extension from the Sea-tac Airport to the new S 200th Street Park and Ride Station. Michael design several noise walls for noise mitigation between the Airport Station and the new park and ride. He also specified resilient fasteners for vibration mitigation along a segment of the elevated trackway. Michael was required to support or testify in several court challenges related to noise, meet with affected property owners, and worked closely with Sound Transit on the final design of the trackway and station configuration.

East Link Light Rail EIS, CH2M Hill, Inc. /Sound Transit, Seattle, Washington

Michael is the Noise Analyst for the new East link light rail extension from Seattle to Redmond, Washington. Noise analysts at MM&A measured and analyzed existing noise conditions and predicted potential noise and vibration impacts. Michael worked closely with CH2M Hill and Sound Transit during the screening process, and also attended public meetings in support of the project. Michael authored the noise technical report. Michael is currently working with CH2M Hill on a second round of screening for four new alternatives in Bellevue.

Seattle Light Rail Initial Segment, Sound Transit, Seattle, Washington

MM&A, along with ATS Consulting was recently awarded an on-call noise and vibration contract directly with Sound Transit. Michael is performing post-construction noise and vibration testing of the initial segment from downtown Seattle to the Sea-Tac Airport. Testing includes performing noise and vibration measurements, verifying noise impacts and mitigation, and performing a supplemental noise and vibration analysis. Michael performed direct testing of trains to assure they meet contract specifications while working with Sound Transit to reduce noise levels of train mounted and intersection warning systems. Michael identified a section of track with vibration issues that were due to improper track grinding and is working with Sound Transit to solve potential issues with rail corrugation and increased noise levels.

Lane County Transit District Rapid Transit Corridor, OTAK/Lane Transit District, Eugene, Oregon

Milwaukie Light Rail Extension, Parametrix, Inc. /TriMet, Portland, Oregon

Michael is the Task Manager for noise and vibration analysis of an eight mile corridor of proposed light rail track. Michael is responsible for noise and vibration analysis and mitigation measures using the FTA Noise and Vibration Manual and criteria. Tasks include analysis of noise and vibration levels, performing an additional vibration propagation test and providing noise and vibration mitigation measures where required.

Tacoma Light Rail Project

Parametrix, Inc. /Sound Transit, Tacoma, Washington

Michael was the Task Manager for noise and vibration analysis on a five mile corridor of proposed light rail track. Responsibilities included measuring and analyzing existing noise and vibration conditions, measuring vibration propagation characteristics, and predicting potential noise and vibration impacts. Michael also analyzed potential impacts near proposed transit stations for traffic noise impacts, and analyzed potential impacts due to added bus routes that are part of the project. Michael was responsible for co-authoring the noise and vibration results report and interfacing with the client.

Tacoma - Lakewood Commuter Rail Project

Berger ABAM/Sound Transit, Tacoma, Washington

Michael was the Task Manager for noise and vibration analysis on a fifteen mile corridor of existing freight train track. Responsibilities included measuring and analyzing existing noise and vibration conditions, measuring vibration propagation characteristics, and predicting potential noise and vibration impacts due to the added use of the corridor for commuter rail traffic. Michael analyzed potential impacts near proposed transit stations for traffic noise impacts and was responsible for writing the noise and vibration results report, interfacing with the client, and attending public meetings.

Seattle - Everett Commuter Rail Project

Sound Transit, Seattle, Washington

Michael was the Task Manager for noise and vibration analysis of commuter rail traffic on a thirty mile corridor of existing freight train track. Michael was responsible for measuring and analyzing existing noise and vibration conditions, measuring vibration propagation characteristics, and predicting potential noise and vibration impacts due to the added use of the corridor for commuter rail traffic. Michael also analyzed potential impacts near seven proposed transit stations for traffic noise impacts. Michael was responsible for writing the noise and vibration results report, interfacing with the client, and attending public meetings.

Lane County Transit District Rapid Transit Corridor

OTAK/Lane Transit District, Eugene, Oregon

Michael is the Task Manager for noise and vibration analysis of the proposed West Eugene Expressway rapid bus transit corridor. Analysis requirements include predicting potential noise impacts due to added bus only transit lanes, and park and rides associated with the transit corridor. This project required detailed on-site noise monitoring, the use of the FHWA Traffic Noise Model (TNM version 2.5) construction of detailed traffic noise models, and modeling the traffic noise along several major streets in the Eugene area. Due to the complex analysis requirements, the analysis used criteria from the FHWA and FTA for final impact analysis. Recommended noise mitigation and also provided an analysis of construction noise. Michael was also responsible for attending public meetings, interfacing with the client, and authoring the noise technical report.

Metro Interstate MAX Light Rail Project

Parametrix, Inc. /TriMet, Portland, Oregon

Michael was the Task Manager for noise and vibration final design on a ten mile corridor of proposed light rail track. Michael was responsible for assisting Metro with final noise and vibration mitigation measures. Tasks included additional analysis of vibration levels and vibration projections inside nearby residential land use. Michael was also responsible for deriving mitigation measures including a residential insulation program (RSIP).

Air Quality

228th Street SW Corridor Project, City of Edmonds, Edmonds, WA

The City of Edmonds wishes to reduce congestion and solve key safety issues for vehicles accessing SR 99 by providing protected left-turn phasing for both approaches and restricting left turns from SR 99 onto 76th Avenue W. The analysis examined CO concentrations using WSDOT�s Washington State Intersection Screening Tool (WASIST) and the results of this analysis demonstrate that carbon monoxide concentrations resulting from this project will not create new violations of the National Ambient Air Quality CO Standards (NAAQS. Therefore, this project met the transportation conformity requirements, and no additional air quality mitigation measures were required.

F-Line Rapid Ride Extension Project, King County, Renton, Wa

MM&A performed an examination of the air quality impacts resulting from the extension of the F-line Rapid Ride transit system approximately 1.5 miles from its original terminus at the Renton Transit Center (Burnett Avenue S /South 3rd) Street in Renton, Washington. The analysis were based upon WSDOT and FHWA guidance and modeling in the Synchro software implementation of the Highway Capacity Manual. The results of the hotspot analysis demonstrated that the intersection would not meet or exceed the National Ambient Air Quality Standards for carbon monoxide.

Main Street Realignment Project, City of Kelso, Washington

The analysis examined CO concentrations using WSDOT's Washington State Intersection Screening Tool (WASIST) and the results of this analysis demonstrate that carbon monoxide concentrations resulting from this project will not create new violations of the National Ambient Air Quality CO Standards (NAAQS). Therefore, this project met the transportation conformity requirements, and no additional air quality mitigation measures were required.

Fred Hill Materials, Shine Washington

Three studies of the noise impacts of a large sand and gravel operation. The first was an extensive study of the noise impacts of an existing 1 million TPY sand and gravel operation, the second study was an analysis of the effects of the excavation activities moving to a new nearby area. The third determined the noise impacts of building a ship-loading facility on Hood Canal. In the first two studies simultaneous 24-hour measurements were taken at 6 locations and the results were compared to the King County Noise Code. To determine future noise levels when the mine�s working face is moved the 1/3 octave band noise signatures of the mining machinery were measured and input in the Environmental Noise Model. The third study (Pit-to-Pier Project) used the CADNA A noise model. All the studies indicated that the existing operations did not exceed State or County noise standards during periods of normal meteorology. In the second study, the Proposal to relocate the working face was found to generate less noise than the current operations.

Seattle Public Utilities, Solid Waste Utility Supplemental EIS Air Quality and Noise Chapters, Seattle, Washington

A study of the air quality and noise impacts of system-wide changes to the City of Seattle solid waste trucking system. Air quality impacts are from changes in garbage truck vehicle-miles and dust control and filter systems for an intermodal solid waste transfer facility. Noise impacts are from changes in automobile traffic and truck traffic and the waste handling machinery used on site.

S.E. Mill Plain Blvd. / 136th Avenue Corridor Improvements, Vancouver, WA

The Vancouver region is classified as a �maintenance area� for carbon monoxide and in �attainment� for ozone. Because of the low level of service at the intersection, a quantitative analysis was required. The analysis showed that overall the intersection improvements will cause a slight decrease in vehicle emissions as the project will reduce vehicle delay at the intersection. This project is part of the 2007 Update of Clark County�s Metropolitan Transportation Plan (MTP), which has been found to meet Conformity requirements.

Nyberg Road + I-5 interchange Improvements

This study was an analysis of the impacts upon air quality resulting from improvements to the I-5 Nyberg Road interchange. This project will add two eastbound lanes to the Nyberg Road overpass and will make changes to the southbound and northbound off ramps. This report presented the results of air quality modeling which is based upon the use of air quality models developed by the US. Environmental Protection Agency (EPA) for predicting concentrations of carbon monoxide- the pollutant of most concern for transportation projects. Modeling was performed for both of the signalized off ramp intersections. They are currently operating at a LOS of C and D and are projected to operate at E and D in 2020 after the project improvements are built. No exceedances were found and no mitigation measures were required.

Rockets, Bridges, and Other Unique Projects

Kodiak Launch Complex Space Launch Vehicle Noise Monitoring

R&M Consulting, Anchorage Alaska

Michael is the Noise Analyst for the measurement and analysis of space launch vehicles noise from the Kodiak Launch Facility as part of a larger environmental study. Michael�s was task with capturing a complete picture of the launches using MM&A�s detailed noise level analyzers. Michael was successful in obtaining complete data sets from each of the last seven launches under this environment contract. The data included the A-weighted Leq, Lmax and Lmin, complete statistical information, the C-weighted Lpeak and detailed (Leq, Lmax and Lmin) un-weighted 1/3 octave band noise levels from 12.5 Hz to 20,000 Hz along with high quality audio recording of rocket launches. The data was summarized and presented in launch reports along with supporting information.

Bend Airport Improvement and Expansion Plan Noise and Air Quality Analysis

Bend Airport and David Evans and Associates, Bend, Oregon

The proposed action consisted of three phases and included expansion of the Epic Aircraft facility, a new eastside taxiway, future industrial development, and new associated internal access roads. Michael performed airport noise and air quality modeling and analysis for the Bend Airport project using methods provided by the FAA. Modeled three different years using INM version 7.0a. Modeling was performed for several types of aircraft including several types of propeller aircraft, business jets, and helicopters. Identified several residential and commercial impacts and recommended noise mitigation measures. Plotted aircraft noise level contours and authored a detailed noise report. Also performed an airport-related air quality study for the new fuel and storage systems and also evaluated the potential for air quality impacts from increased aircraft operations. Evaluated all engine powered equipment, fuel storage areas, and flight traffic in accordance with the FTA regulations.

Boardman Bombing Range Complex New Weapons Training Ranges Noise Analysis

Oregon Army National Guard and Mason Bruce and Girard, Boardman, Oregon

The Oregon Military Department (OMD)/Oregon Army National Guard (ORARNG) prepared this Environmental Assessment (EA) to address the potential environmental effects related to the proposed construction and operation of two permanent weapons training ranges and support areas and two portable Convoy Live Fire Ranges (CLFRs) at the Naval Weapons Systems Training Facility, Boardman [also known as the Boardman Bombing Range Complex (BBRC)], located near the city of Boardman, Oregon. The task of MM&A was to project the noise from weapons using the ranges with the Army Statewide Operational Noise Management Plan. MM&A projected the noise levels based on Army Regulation 200-1and the three Land Use Planning Zones (LUPZ) zones for the evaluation of community annoyance (noise zones III (NZ III), II (NZ II) and I (NZ I). Mr. Minor worked closely with the U.S. Army Center for Health Promotion and Preventive Medicine (USACHPPM) on the noise projections and determining potential impacts from the firing of M1 A2/A3 main battle tanks, M2A1/M3A1 Bradley Fighting Vehicles and miscellaneous small arms weapons. Michael Minor authored the noise section of the Environmental assessment and worked to support other discplines in their work that was related to noise.

LRI Landfill BioFuels Renewable Energy Plant

SCS Engineers, Pierce County Washington

Michael Minor was the lead noise technical expert and performed a detailed noise analysis for a proposed landfill gas (LFG) to energy power plant. Tasks included installation of three semi-permanent noise monitoring systems that were used to establish the existing conditions and locate sites for compliance noise monitoring was the project was installed and running. Michael performed a detailed noise analysis and predicted noise levels at several nearby residences, worked closely with the project design team to develop an installation that could meet the stringent Pierce County noise control regulations. Michael also provided a building certification as required by Pierce County Ordinance.

Power Resource Cooperative Coffin Butte Electrical Power Plant, Corvallis Oregon

Pacific Northwest Generating Cooperative, Portland, Oregon

Performed compliance noise monitoring for the Coffin Butte Electrical Plant, just north of Corvallis Oregon. Performed initial noise testing prior to facility installation, monitored noise after initial star-up, and performed supporting noise measurements whenever a new generator was brought on-line. Measured levels at the facility and also at nearby residences to verify that operations of the facility meet state noise control regulations.

St. Johns Bridge Rehabilitation Project

Oregon Department of Transportation, Noise Analyst, Portland, OR

MM&A performed 24-hour, continuous construction noise monitoring in three established residential areas during the rehabilitation of the St. Johns Bridge. Prior to construction we also performed ambient noise monitoring, calculated reduction factors for the neighborhood and determined optimal sound level meter placement for noise monitoring. MM&A worked with ODOT to obtain a noise variance from the City of Portland for nighttime construction activities. We made weekly reports and analysis of data, attended public meetings, and conducted a workshop on sound level meter care and operation. We also met with affected residences and assisted with noise mitigation measures to assure compliance with the noise variance.

Sellwood Bridge Replacement Project

Multnomah County, Noise and Vibration Analyst, Portland, OR

MM&A is currently performing 24-hour, continuous construction noise and vibration monitoring at four different sites during the Sellwood Bridge Replacement Project. We performed ambient noise monitoring, calculated reduction factors for the neighborhood and determined optimal sound level meter placement for noise monitoring. Made weekly reports and analysis of data, attended public meetings, and conducted a workshop on sound level meter care and operation. The rendering of the new bridge to the right is from the project web site at sellwoodbridge.org

Interstate 5 Bridge Rehabilitation Project

Oregon Department of Transportation, Noise Analyst, Portland, OR

MM&A performed 24-hour, continuous construction noise monitoring at three different hotels during the painting and repair to the Interstate 5 bridge. We performed ambient noise monitoring, calculated reduction factors for the neighborhood and determined optimal sound level meter placement for noise monitoring. Made weekly reports and analysis of data, attended public meetings, and conducted a workshop on sound level meter care and operation.

Ross Island Bridge

Oregon Department of Transportation, Noise Analyst, Portland, OR

MM&A performed 24-hour, continuous construction noise monitoring at six different residences, relocating the noise meters based on construction activities, for the construction and upgrades to the Ross Island Bridge. We performed ambient noise monitoring, calculated reduction factors for the neighborhood and determined optimal sound level meter placement for noise monitoring. MM&A also worked with ODOT to obtain a noise variance from the City of Portland for nighttime construction activities. Made weekly reports and analysis of data, attended public meetings, and conducted a workshop on sound level meter care and operation. We also met with affected residences and assisted with noise mitigation measures to assure compliance with the noise variance.

Hawthorne Bridge

Multnomah County, Noise Analyst, Portland, OR

MM&A performed 24-hour, continuous construction noise monitoring during the painting and repair to the Hawthorne bridge. We performed ambient noise monitoring, made weekly reports and analysis of data and attended public meetings.

Oregon Bridge Delivery Partners Projects

Oregon Department of Transportation, Oregon

MM&A worked on eleven of the Oregon Bridge Deliver Partners (OBDP). Our work allowed the replacement or rehabilitation of several bridges in the state of Oregon. Some of the bridges analyzed as part of this family of projects includes the I-84 Bridge, Irrigon Junction � Hilgard Interchange, the Jumpoff Joe Creek Bridge (north and south bound) the Beacon Drive Bridge and the South Wolf Creek Bridge, all on Hwy 1. We also worked on the Saginay Road, Brown Creek and Camas Swale Bridges, all associated with Highway 1. MM&A also performed a detailed traffic noise analysis for the replacement of the Riddle Road On-Ramp Structure and a direct access north bound on ramp from Riddle Road to I-5.
